224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯发电厂用热车机汽柴油社会效率性好: 先进性的汽柴油抑制体统，独特的的STC、ESTC 划分抑制体统，特有设计方案的汽缸上方进行焚烧仓，高压变压器喷洒于汽柴油，有力做雾化，进行焚烧有力。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯并网发电用起动因瞬态能力非常好的: 终极的起动因总体的设计，能默契配合康明斯现代感的EFC体系，操纵的精密度不高，反映耗时快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯火力发电用热车机升电机功率高: 整体风格制定狭窄.外表布置准备正确，进行平稳性。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷手机型号 QSNT. QSK19. QSK38. QSK50具备中国国家非公路第三步时期及美国Tier2. Tier 3废气政策法规让。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零零备件可获性好， 打火机使用及维持皮肤保养快捷，成本预算低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

输出功率空间 Power Range   224-310KW形式 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外型规格尺寸 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净产品质量 Dry Weight   940kg

224-310KW康明斯发电机组用启心理的特性：球设备体积较小， 压解比较高， 格栅价格自然空气调温，也容易打火，挪动汽车导航24v电源的省心。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

热车机主要参数	通用最大功率(kW)Prime Power	预备功效kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
